Mode No.: TXC-0.5E
Size: 4880x1150x1825mm (shipping status)
Rated load weight:1t
Bucket capacity: 0.5m3
Empty weight: 4.5t
Shovel pickup force: 42kn
Tractive force: 45kn
Power: 37kw
Speed (full loading): 0-12kw/h (two way)
Advantages:
▬The ultra-small LHD is especially suitable for mining in narrow and low roadways and difficult-to-mine areas.
▬The closed hydrostatic and stepless transmission driving system composed of variable piston pump and variable piston motor greatly improves production efficiency;
▬Using electric motor as power source, no pollution, low energy consumption, plateau motor can be optional in high altitude areas;
▬The cable retraction is controlled by the hydraulic cable valve, which effectively protects the cable from excessive stretching and prolongs the service life
